Industrial Drone Thermal Camera with Gimbal Stabilizer Public Security Firefighting Border Defense 30x to 40x Optical Zoom Satellite Positioning Systems

Industrial Drone Thermal Camera with Gimbal Stabilizer Public Security Firefighting Border Defense 30x to 40x Optical Zoom Satellite Positioning Systems

CHOICECYCLE CCTV offer the best Industrial Drone Thermal Camera with Gimbal Stabilizer Public Security Firefighting Border Defense 30x to 40x Optical Zoom Satellite Positioning Systems

1. Features:
   • Thermal Imaging Capability: Equipped with thermal sensors for heat detection, allowing for enhanced situational awareness.
   • Gimbal Stabilizer: Integrated gimbal system for stabilized and smooth footage, compensating for drone movements.
   • High Optical Zoom (30x to 40x): Allows the drone to capture detailed images from a considerable distance, critical for surveillance and reconnaissance.
   • Satellite Positioning Systems: Integration with GPS or other satellite positioning systems for precise navigation and location tracking.
   • Advanced Imaging Technology: Utilizes advanced imaging technologies for better image quality and analysis.
2. Functions:
   • Public Security: Supports public security operations by providing real-time surveillance and monitoring capabilities.
   • Firefighting Support: Enables firefighters to assess and monitor the situation in real-time, helping with decision-making and resource allocation.
   • Border Defense: Used for border patrol and defense purposes, enhancing surveillance and response capabilities.
   • Search and Rescue Operations: Aids in search and rescue missions by providing aerial views and thermal imaging for locating individuals.
3. Benefits:
   • Enhanced Surveillance: High optical zoom and thermal imaging capabilities improve surveillance effectiveness, especially in large or challenging terrains.
   • Rapid Deployment: Drones offer quick deployment for timely response in emergency situations or security incidents.
   • Safety: Provides an aerial perspective without risking human lives, making it suitable for dangerous or inaccessible areas.
   • Efficient Resource Management: Helps in efficient allocation of resources during firefighting or security operations.
4. Advantages:
   • Versatility: Suitable for a wide range of applications including public security, firefighting, and border defense.
   • Precision and Accuracy: Satellite positioning systems contribute to precise navigation and location-based data.
   • Remote Monitoring: Enables real-time monitoring from a remote location, improving overall operational efficiency.
   • Data Integration: Capable of integrating with data analytics systems for more comprehensive analysis.

For the most accurate and up-to-date information about specific industrial drone thermal cameras with gimbal stabilizers, please refer to the product documentation, contact the manufacturer directly, or check their official website, as product details and advancements may have occurred after my last knowledge update in January 2022.



Flight Height 2km, Transmission Distance 3km-10km, Flight Time 60mins.

This product is a hexrcopter drone which includes the aircraft, payload, remote control.
It’s designed for public security, transportation, firefighting, border defense, agricultural and forestry, and energy industries. It provides a complete aerial video surveillance solution with
long transmission distance, high hovering accuracy, and 30x/40x optical zoom capabilities.
Intelligent Mode
The drone supports convenient operation with multiple intelligent modes, including flight route, waypoint flight, circle (points of interest), and direction lock mode.
The drone can take off automatically and enable intelligent mode, moving according to the pre-set route / waypoints and points of interest.
When the mission is finished, the drone will return to base and land automatically.
Security Mechanism
There are a series of security mechanisms which ensure safe and reliable drone operation.
If the drone runs out of battery or moves out of the control range, it will signal an alarm and return to base automatically, triggering landing mode.
E-Fence functionality makes setting flight boundaries easy, preventing the drone from flying into restricted areas.
Quick Assembly and Disassembly
All parts of the drone, including the battery, payload, propellers, antenna, and aircraft arms can be quickly assembled and disassembled, ensuring immediate mission readiness as well as quick extraction.
A variety option of payload
The drone supports to carry multiple payloads , such as visible light PTZ camera (2MP, 6MP, 4K), IR thermal PTZ camera, loudspeaker, casting device,
which is suitable for critical surveillance tasks such as power line inspection, forest fire detection, public event management, bridge security, and police detection.
Accurate Positioning
Three satellite positioning systems used by the drone – GPS, Beidou, and GLONASS – ensure high accuracy positioning with ±1.5m horizontal and ±0.5m vertical accuracy.
These three positioning systems also ensure near complete coverage of the global market.

Dahua Technology World Introduction HERE

Technical Specification
Aircraft Diagonal Wheelbase 1550mm, Dimensions 1640(mm) x 585(mm) x 1420(mm), Package Dimensions 942(mm) x 687(mm) x 931(mm)
Satellite Positioning Systems GPS/ Beidou /GLONASS, Net Weight 7.0kg(15.43lb), Max. Takeoff Weight 23.6kg(52.02lb)
Flight Parameter Max. Flight Time (No Payload) 60mins, Hovering Power 1300W, Hovering Accuracy Vertical: ±0.5m , Horizontal: ±1.5m(<Lev.3 wind)
Max. Speed 15m/s, Max. Flight Height 2000m(6561.7ft), Max. Takeoff Altitude 5000m(16404.2ft), Max. Ascent Speed 11m/s, Max. Descent Speed 2.5m/s
Max. Tilt Angle 20°, Max. Wind Speed Resistance 15m/s, Max. Angular Velocity 50°/s, Operating Temperature -20°C ~ 60°C (-4°F ~ 140°F),
Power Battery Capacity 2*27000mAh/pcs, Battery Type LiPo, Net Weight 2*3.3kg (7.27lb)/pcs, Operating Temperature -20°C ~ 60°C(-4°F ~ 140°F),
Storage Temperature -30°C ~ 65°C (-22°F ~ 149°F), Remote Controller, 4G LET Support, Protocol Support Onvif, SIP, RTSP and Dahua private protocol,
Port Audio In, Micro SD Card Slot up to 256GB, VPN Support, Max Transmission Distance 3-10Km
Screen 7″ touch screen, Battery 2S LiPo, 7800mAh, Working Time 5hours, Operating Temperature -20°C ~ 60°C (-4°F ~ 140°F), Storage Temperature -30°C ~ 65°C(-22°F ~ 149°F)

Industrial Drone Thermal Camera with Gimbal Stabilizer Public Security Firefighting Border Defense 30x to 40x Optical Zoom Satellite Positioning Systems



DHI-UAV-GA-TV-2030TA Thermal Hybrid PTZ Camera

· 640×512 VOx uncooled thermal sensor technology, Support temperature measurement, 1/2.8” STARVIS™ CMOS, Powerful 30x Optical Zoom, Support Defog
· Anti-vibration Axis 3 Axis, Support Flight Plantform: X820, X1100, X1550.
Technical Specification(Payload) Visual Light Parameter, Sensor 1/2.8” STARVIS™ CMOS
Max.Image Restion 1920(H)x1080(V), 2 Megapixels Mim. Illumination Cor:[email protected]
B/W:[email protected] Defog Support, Electronic Shutter Speed 1/1s~1/30,000s
Electronic Image Stabilization (EIS) Support, Focal Length 4.5mm~135mm, Digital Zoom 16X, Optical zoom 30x
640×512 VOx uncooled thermal sensor technology, Support temperature measurement, 1/2.8” STARVIS™ CMOS
· Powerful 30x Optical Zoom, Support Defog, Anti-vibration Axis: 3 Axis, Support Flight Platform: X820, X1100, X1550

DHI-UAV-GA-TV-2030TA Thermal Hybrid PTZ Camera
Angle of View H: 67.8° ~ 2.77° , Max. Aperture F1.6 ~ F4.4,

Frame Rate
Main stream: 1080P/720P/704×480 (1~25/30fps), Sub stream1: 704×480/352×240(1~25/30fps)
Video Compression H.265/H.264+/H.264, Storage Micro SD Card 128G,
Thermal Parameter Resolution 640*512, Lens 19mm, Digital Zoom 16x,

Frame Rate
Main stream: 1280×1024/720P(1~25/30fps)
Sub stream1: 640×512/320×256 (1~25/30fps)
Temperature Range(Low) -20 ~ 160°C
Thermal Sensitivity <30mK@f/1.0
Temperature Range(High) 160 ~ 550°C
Temperature Tolerance ≤2%
PTZ Parameter
Precision ±0.01°
Anti-vibration Axis 3 Axis
Pan/Tilt Range Pan: ±170°; Tilt: -90° ~ 45°
Pan/Tilt Speed Pan: 130°/s; Tilt: 130°/s
Gimbal Dimension 226.7*207.6*131.9mm
Gimbal Features Cruise following
Cruise locked
Auto-tracking Support
3D positioning: Support
Protection Level: IP54
Working Environment. Temp. -20 ~ 60°C
Net Weight 1275g
