CCTV Singapore Isolator UTP Eliminate ground loop problem Prevents power cables interfering CCTV Video Wavy Running Distortion

CHOICECYCLE CCTV help to provide solutions for CCTV Singapore Isolator UTP Eliminate ground loop problem Prevents power cables interfering CCTV Video Wavy Running Distortion

Features:

BNC male to terminal block with 15cm mini coax cable
Passive type, no power need
Hi Performance to eliminate ground loop problem
Low video loss, Bandwidth: 20hz -11Mhz ,+0/-3Db
Prevents video-signal distortion caused by video ground loops
Eliminates picture tearing, cross talk and rolling
Prevents power cables laid by others interfering with the CCTV system
Weight: 156g/pair

Twisted Pair Ground Loop Isolator for UTP (GP100) Insertion Loss 0.5dB Frequency Response 20HZ- 10Mhz,

+0/-3dB Input Resistance 75 ohm Output Resistance 100 ohm Isolation Voltage 600VDC (Min) Insulation Resistance

100M Ohm Transient Voltage Suppressor 12 Vrms Dimensions (mm) 72x28x22 Material ABS Black

1. Collection from SGCCTV   Choicecycle Sim Lim Square CCTV SPECIALIST #02-81 11am~8pm. Whatsapp 90254466 for stock level before visit.

2. Payment by PayNow 90254466 & Paylah QR code will receive Free Gift Warning Stickers worth $20.00 (1pc per client order)
3. Please add $18.00 for delivery – 3~5 days.
4. Can issue e-Invoice for your accounting. (upon request)

HIKVISION CCTV CAMERA PTZ

HIKVISION DS-2CE70DF0T-MF ColorVu Dome ||  Hikvision DS-2CE16D1T-IT3 2MP 1080P Bullet  ||
HIKVISION 4MP DS-2CD1343G2-I(UF) || Hikvision 4MP POE DOME Camera DS-2CD1143G2-LIU ||

HIKVISION SOLAR-POWER 4MP DS-2XS2T47G1-LDH/4G || Hikvision POE Bullet Camera DS-2CD2T23G0-I5-I8  ||

Hikvision POE Bullet Camera DS-2CD2023G2-I ||  HIKVISION 4MP Motorized Varifocal DS-2XC6645G0  ||

HIKVISION 4MP Motorized Varifocal DS-2CD2643G2-IZS ||  HIKVISION LICENSE PLATE CAMERA DS-TCG405-E ||

Marine Grade CCTV SINGAPORE HIKVISION DS-2XE6222F-IS  ||  HIKVISION CCTV CAMERA BRACKET DS-1260ZJ ||

HIKVISION CCTV DVR NVR

CCTV NVR Hikvision DS-7604NI-Q1/4P  ||  HIKVISION DVR eSSD iDS-E04HQHI-B ||

HIKVISION POE SSD NVR DS-7804N-SSD  || HIKVISION 8CH Mobile NVR AE-MH0408||

HIKVISION 16CH Mobile NVR DS-MP7608HN/GLF/WI58  || HIKVISION 32CH NVR Video Recorder DS-MP3516-RH  ||

CCTV NVR Hikvision DS-9632NI-M8 DS-9664NI-M8  ||

The CCTV Singapore Isolator UTP, designed to address specific issues commonly encountered in CCTV systems, offers several features and functions:

1. Ground Loop Elimination:

• Purpose: Ground loops can cause interference and distortions in video signals due to voltage differences. The isolator is designed to eliminate ground loop problems that can affect video quality.
• Function: It prevents unwanted interference caused by differences in ground potential between interconnected devices, ensuring a cleaner and more stable video signal.

2. Interference Prevention:

• Power Cable Interference: The isolator aims to prevent power cables from interfering with the CCTV video signals, reducing or eliminating wavy or distorted images that may occur due to electrical interference.
• Minimizing Distortion: By mitigating interference from power cables, it helps in reducing distortions, wavy images, or running lines that can affect the clarity of CCTV video feeds.

3. Maintenance and Repair:

• CCTV Camera Stability: Installing isolators can help in stabilizing video feeds and reducing potential issues caused by electrical interference, contributing to smoother video transmission and reducing the need for frequent camera repair or replacement.
• Repair and Replacement: While the isolator addresses certain interference issues, it’s essential to note that it does not replace the need for proper maintenance, repair, or replacement of faulty CCTV cameras or components. It works in conjunction with regular maintenance practices.

4. Functionality:

• Compatibility: These isolators are typically compatible with UTP (Unshielded Twisted Pair) cables commonly used in CCTV systems.
• Installation: They are installed in-line between the camera and the receiver or recording device to ensure the video signal passes through the isolator before reaching the monitoring equipment.

Overall, the CCTV Singapore Isolator UTP serves to enhance the performance and stability of CCTV systems by addressing ground loop issues and preventing interference caused by power cables, thereby improving video quality and reducing potential distortions or running lines in CCTV footage. However, for complex issues or severe distortions, professional CCTV camera repair or replacement might still be necessary to ensure optimal system performance.



CCTV Singapore Isolator UTP Eliminate ground loop problem Prevents power cables interfering CCTV Video Wavy Running Distortion

To set up and prevent CCTV video distortion caused by ground loops and power interference in Singapore or any location, you can take several measures:

Setup:

1. Isolators and Baluns: Use isolators or baluns specifically designed for CCTV systems. These devices help eliminate ground loops and can transmit video signals over UTP (Unshielded Twisted Pair) cables, reducing interference.
2. Quality Cables: Invest in high-quality shielded cables for both power and video transmission. Good shielding helps prevent interference from other electrical sources.
3. Separate Power and Video Cables: Keep power cables separate from video cables. Running them parallel or bundled together can induce interference.
4. Proper Grounding: Ensure proper grounding for all CCTV equipment. This helps to minimize ground loop issues.
5. Power Conditioners/Regulators: Use power conditioners or voltage regulators to maintain a consistent and clean power supply to your CCTV system.

Prevention:

1. Regular Maintenance: Periodically inspect and maintain your CCTV system. Check cables, connections, and devices for any wear or damage.
2. Electrical Inspection: Ensure that the electrical wiring in the installation area complies with safety standards and is properly grounded.
3. Surge Protectors: Install surge protectors to safeguard your CCTV system from power fluctuations and surges.
4. Noise Filters: Consider using noise filters or suppressors to reduce electrical interference.
5. Professional Installation: If possible, have your CCTV system installed by professionals who are familiar with grounding techniques and best practices to minimize interference.

Always follow safety guidelines and consider consulting with a CCTV expert or an electrician when setting up or troubleshooting issues to ensure the best performance and safety of your system.
