Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 UTEPO Managed Switch Ethernet Web network management and PoE management L3 Management Multicast Management
in stock
$1137.50
CHOICE Brand and SGCCTV Brand are Singapore IPOS Trade Mark Registered.
Widely deployed in Shopping Malls, Residential, Commercial, Office, Warehouse.
Compatible with ALL DVR & NVR ONVIF protocols.
Great Technical Support at Sim Lim Square 02-81 11am~7pm Daily +65 98534404
in stock
Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 UTEPO Managed Switch Ethernet Web network management and PoE management L3 Management Multicast Management
CHOICECYCLE CCTV offer best quality Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 UTEPO Managed Switch Ethernet Web network management and PoE management L3 Management Multicast Management
Features:
- 24 Gigabit Ports: Provides high-speed connectivity for numerous devices within a network.
- PoE (Power over Ethernet): Delivers power to connected devices such as IP cameras, VoIP phones, and wireless access points through Ethernet cables, eliminating the need for separate power sources.
- Managed Switch: Offers advanced management capabilities for optimizing network performance and security.
- L3 Management: Supports Layer 3 functionality, enabling routing and advanced network configurations.
- Ethernet Web Network Management: Allows for configuration and monitoring of the switch via a web-based interface, facilitating easy management.
- Multicast Management: Facilitates efficient distribution of data to multiple recipients on the network, reducing bandwidth usage.
- UTP7624GE-POE-L3 Model: Specific model number for identification and compatibility purposes.
- Quality of Service (QoS): Prioritizes network traffic to ensure critical applications receive the necessary bandwidth and performance.
Functions:
- Port Configuration: Enables users to configure individual ports for specific purposes, such as VLAN assignment or PoE settings.
- VLAN Support: Segments the network into virtual LANs for improved security and performance.
- Link Aggregation: Combines multiple ports to increase bandwidth and provide redundancy.
- Security Features: Implements features like Access Control Lists (ACLs) and port security to protect against unauthorized access and attacks.
- Monitoring and Reporting: Provides real-time monitoring of network traffic and performance metrics, with reporting capabilities for analysis and troubleshooting.
- PoE Management: Allows for the monitoring and control of PoE-powered devices, including power allocation and scheduling.
Benefits & Advantages:
- Simplified Deployment: Offers plug-and-play functionality for quick and easy setup.
- Power Efficiency: Reduces energy consumption by integrating PoE technology and power management features.
- Cost Savings: Eliminates the need for separate power outlets and reduces cabling complexity.
- Scalability: Scales easily to accommodate growing network demands with additional ports and management features.
- Enhanced Flexibility: Provides a range of management options to tailor the switch to specific network requirements.
- Improved Performance: Optimizes network performance with advanced management capabilities and Quality of Service features.
- Reliability: Ensures continuous operation with features like link aggregation and redundant power options.
- Centralized Management: Streamlines network administration through centralized management interfaces.
- Future-Proofing: Supports advanced networking technologies and standards to accommodate future upgrades and expansions.
Considerations:
- Cost: Initial investment and ongoing maintenance costs should be evaluated.
- Compatibility: Ensure compatibility with existing network infrastructure and devices.
- Training: Staff may require training on the use of advanced management features.
Overall, the Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 from UTEPO offers a comprehensive solution for managing network infrastructure, combining high-speed connectivity, power distribution, and advanced management capabilities to meet the demands of modern networks.
ADVANTAGES
• Provide 24* PoE Gigabit downlink Ethernet ports , 4* 10Gigabit uplink SFP ports.
• Provide web- based layer 3 network management and PoE management by simple operation.
• Support One-key CCTV/LOCK/ONLINE/RING.
• Support high-speed data forwarding, very suitable for large flow of video data forwarding in security surveillance.
• Support recovery of IP address & user password by one key recovery button.
• Quick Installation, simple operation, convenient for wall/desk/rack installation.
Gigabit Switch Router CCTV Camera Video Intercom Face Biometric Door Access Control Network Segmentation Remote Monitoring Data Storage
The 24 ports PoE Gigabit managed Ethernet switch(abbreviated to 24P switch), which provide 24* PoE Gigabit downlink Ethernet ports , 4* 10Gigabit uplink SFP ports. The Products support IEEE 802.3 af/at, support Web layer-3 network management and PoE management. Products are widely used in security surveillance, network engineering projects and so on. The 16 ports PoE Gigabit managed Ethernet switch(abbreviated to 16P switch), is similar to 24P switch only the downlink ports quantity is 16,and the power watts is 320W while the 24P switch’s is 450W.
Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 UTEPO Managed Switch Ethernet Web network management and PoE management L3 Management Multicast Management
The Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 from UTEPO is a managed network switch with various features and functions designed for Ethernet network management and Power over Ethernet (PoE) management. Here are the key features and functions of this switch:
- 24 Gigabit Ethernet Ports: This switch has 24 Gigabit Ethernet ports, which provide high-speed connectivity for your network devices.
- Power over Ethernet (PoE): The switch supports PoE, which means it can provide power to compatible devices like IP cameras, VoIP phones, and access points through the Ethernet cables, eliminating the need for separate power sources.
- Layer 3 (L3) Management: This switch supports Layer 3 routing, allowing it to route traffic between different network subnets. This is useful for creating multiple VLANs and segmenting your network for improved security and performance.
- Web-Based Network Management: The switch offers web-based management, which means you can configure and monitor the switch through a web interface. This provides an intuitive and user-friendly way to manage your network.
- Multicast Management: Multicast management features are essential for efficiently distributing data to multiple recipients. It allows you to control and optimize multicast traffic within your network.
- Quality of Service (QoS): QoS features allow you to prioritize certain types of traffic, ensuring that critical applications receive the necessary bandwidth and network resources.
- VLAN Support: Virtual LAN (VLAN) support allows you to segment your network into multiple virtual networks, helping to improve network security and efficiency.
- Security Features: The switch may include various security features such as access control lists (ACLs), MAC filtering, and port security to protect your network from unauthorized access and attacks.
- Monitoring and Reporting: The switch may offer monitoring and reporting capabilities, allowing you to track network performance, detect issues, and generate reports for analysis.
- Redundancy and High Availability: Some managed switches include features for redundancy and high availability, ensuring that your network remains operational even in the case of hardware failures.
- Remote Management: You can manage and monitor the switch remotely, which is essential for network administrators who need to maintain and troubleshoot the network from different locations.
- Firmware Updates: Regular firmware updates can keep the switch up to date with the latest features and security patches.
Please note that the specific features and functions of this switch may vary depending on the exact model and firmware version. To get a detailed understanding of the capabilities of the UTEPO Gigabit Switch 24Ports PoE UTP7624GE-POE-L3, you should refer to the product’s official documentation or contact UTEPO for more information.
Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 UTEPO Managed Switch Ethernet Web network management and PoE management L3 Management Multicast Management
Model | UTP7624GE-POE-L3 |
Downstream Ports | 24* 10/100/1000Base-T PoE |
Uplink Ports | 4*10G Base-X SFP optical ports (support 1000Base-X by web setting) |
Network Standard | IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X, IEEE 802.1Q IEEE 802.1p IEEE 802.3ad , IEEE 802.1D, IEEE 802.1X |
Switching Capacity | 128Gbps |
Packet Forwarding Rate | 96Mpps |
Forwarding Modes | Store and Forward |
Packet Buffer | 12M |
MAC Address Table | 16K |
PoE Standard | 802.3af/at(PSE) |
PoE Power Method | End-span |
PoE Line Pair | 1/2(+), 3/6(-) |
PoE Output Power | 54V DC , 30 watts max |
PoE Budget | 390 watts max |
Surge Immunity | 6KV Execute: IEC61000-4-5 |
ESD Immunity | 6KV Contact discharge |
8KV Air discharge | |
Execute: IEC61000-4-2 | |
Input Voltage | 100~240V AC, 50/60Hz |
Operating Temperature | -10-50℃ |
Storage temperature | -40-85℃ |
Humidity(Non-condensing) | 5%-95% |
Dimension (L×W×H) | 442mm×305mm×44.5mm |
Weight | 4.35kg |
Certification | CE, FCC, ROHS |
Software Features | |
Port Management | Support port enabling and disabling |
Support port speed settings | |
Support port full-duplex mode | |
Support IEEE802.3x flow control | |
Support Jumbo Frame | |
Support port name modification | |
VLAN | Support of 4K VLAN |
support 802.1Q VLAN protocol | |
support QINQ | |
support GVRP dynamic VLAN register | |
Support VLAN based on port\protocol\MAC | |
Quality of Service | Support COS classification base on 802.1p |
support QoS base on DSCP | |
Support 8 priority queues | |
Queue scheduling: SP, WRR, SP+WRR | |
Support 802.1p CoS/DSCP priority | |
Multicast Management | Support SNMPV1 / V2 / V3 protocols |
Support IGMP Snooping | |
support MLD-snooping | |
POE management | Support Total Power Control |
Support PoE On Off | |
Support single-port 30W output,Output port and priority | |
Security Features | Supports IP, MAC, port, VLAN binding combinations |
Support MAC address auto-learning, aging and filtration | |
Support port isolation, port speed limit | |
Support STP \ RSTP \MSTP,Fast-Ring | |
Support 5 groups of link aggregation | |
support LLDP ,Smart-Link ,DLDP | |
Support 802.1X | |
ACL | support base on source-MAC, target-MAC, protocal-classify, source-IP, target-IP, L4 ports-number |
support time-range management | |
System Management | Web-based GUI and CLI management |
Support FTP / TFTP / HTTP load upgrade | |
Support traffic statistics | |
Support MAC address table query | |
Support IP address, DNS server modifications | |
Support user name and password modification | |
Support for history, log management | |
Support System Configuration Backup | |
Support to recover the default factory settings on reboot | |
L3 Management | support IPV4 static route setup |
support RIP V1/2 on IPV4 | |
support OSPF V1/V2 | |
Support static ARP Add, delete burn-in time sutup/check | |
Support static ND Add, delete burn-in time sutup/check | |
Support VRRP V1/2/3 virtual redundant route protocol | |
Support group-broadcasting PIM,IGMP V1/V2/V3,MLD(IPV4) | |
Support DHCP client, server | |
Support relay repeater DHCP snooping | |
Support duplex transfer check mechanism |
- Collection from SGCCTV Choicecycle Sim Lim Square CCTV SPECIALIST#02-81 11am~8pm. Whatsapp 90254466 for stock level before visit.
- Payment by PayNow 201207820G (Please print screen and whatsapp to 90254466) & Paylah QR code will receive Free Gift Warning Stickers worth $20.00 (1pc per client order)
- Please add $18.00 for delivery – 3~5 days, no further discount as Price guarantee lowest.
- Can issue e-Invoice for your accounting. (upon request)
Gigabit Switch 24Ports PoE UTP7624GE-POE-L3 UTEPO Managed Switch Ethernet Web network management and PoE management L3 Management Multicast Management
Secure Office Building Surveillance System
Components:
- CCTV Cameras: A network of high-definition CCTV cameras placed strategically throughout the office building to monitor entrances, hallways, parking areas, and other critical areas.
- Internet Connectivity: A reliable internet connection is essential for remote monitoring, data storage, and software updates for the security system.
- Intercom System: An intercom system with audio and video capabilities for communication between security personnel and visitors.
- Access Control: A system that manages and restricts access to various parts of the building using keycards, biometric devices, or other secure authentication methods.
- Gigabit Switch Router: This device serves as the central hub of the network, connecting all components and facilitating communication between them.
Usage:
- Camera Integration: The CCTV cameras are connected to the Gigabit Switch Router via Ethernet cables. The router’s high-speed Gigabit ports ensure minimal latency and efficient data transfer from the cameras to the monitoring station.
- Internet Connectivity: The Gigabit Switch Router is connected to the building’s internet gateway. This connection allows the security personnel to access live camera feeds remotely through a secure web interface or dedicated surveillance software.
- Intercom System: The intercom units are also connected to the Gigabit Switch Router. This enables audio and video communication between security personnel stationed at a central monitoring station and visitors at building entrances.
- Access Control Integration: The access control system, which includes card readers or biometric devices at entry points, is connected to the Gigabit Switch Router. This integration allows real-time monitoring of entry and exit events and enables security personnel to manage access permissions.
- Network Segmentation: The Gigabit Switch Router can support VLAN (Virtual Local Area Network) segmentation. This ensures that different components of the security system, such as CCTV cameras, intercoms, and access control devices, are logically isolated from each other, enhancing security and preventing unauthorized access.
- Remote Monitoring: Security personnel can remotely access the surveillance system using a secure VPN connection. This allows them to monitor live camera feeds, communicate with visitors, and manage access control settings even when they are not physically present in the building.
- Data Storage and Analysis: The Gigabit Switch Router can be connected to a Network Video Recorder (NVR) for centralized storage of video footage. Advanced analytics software can also be integrated to analyze camera feeds for unusual activities and generate alerts for potential security threats.
By using a Gigabit Switch Router to connect and manage these various components, you create an integrated and efficient security ecosystem that enhances the safety of the office building and its occupants.
