UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace
>
>
>
UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace

UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace

in stock

$3988.00

UNV UNIVIEW SINGAPORE OFFICIAL PARTNER

Widely deployed in Shopping Malls, Residential, Commercial, Office, Warehouse.
Specialist in all Security System CCTV Camera Door Access Alarm Switch
Technical Support at Sim Lim Square 02-81 11am~7pm Daily +65 98534404 +65 81985572

in stock

- +

UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace

CHOICECYCLE CCTV offer the best UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR.
Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace

The UNV POE NETWORK NVR NVR516-E-R by Uniview is a high-performance network video recorder designed for professional surveillance applications. Here are its features, functions, benefits, and advantages:

  1. Features:
    • 64CH-128CH Support: Capable of supporting 64 to 128 channels, providing scalability to accommodate large-scale surveillance systems.
    • Hot Swap: Supports hot-swappable hard drives, allowing for easy replacement and maintenance without disrupting surveillance operations.
    • RAID Support: Offers RAID configurations including RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, and RAID 60, providing data redundancy and fault tolerance.
    • N+1 Hot Spare: Includes N+1 hot spare functionality, ensuring continuous operation by automatically replacing a failed disk with a spare disk.
    • Cloud Upgrade: Supports cloud-based firmware upgrades, enabling convenient and efficient system maintenance.
    • 16-HDD Support: Accommodates up to 16 hard disk drives (HDDs), providing ample storage capacity for long-term video retention.
    • CCTV Camera Installation, Repair, and Replacement: Can be installed, repaired, or replaced by professional technicians specializing in CCTV systems.
  2. Functions:
    • Video Recording: Records video footage from connected IP cameras, providing continuous or event-triggered recording for surveillance purposes.
    • Playback: Allows users to search and playback recorded footage, enabling investigation of security incidents or events.
    • Remote Access: Enables remote access to live video feeds and playback footage via web browsers or mobile apps, providing flexibility in surveillance monitoring.
    • Event Management: Supports event-based recording and alerts, allowing users to configure triggers such as motion detection or alarm inputs.
    • Health Monitoring: Monitors the health status of the NVR, including hard drive status, temperature, and fan speed, ensuring system reliability and uptime.
    • Integration: Integrates with various security systems and devices, including IP cameras, access control systems, and alarm systems, providing a comprehensive security solution.
  3. Benefits and Advantages:
    • Scalability: The NVR516-E-R offers scalability to accommodate growing surveillance needs, making it suitable for small to large-scale deployments.
    • Data Redundancy: RAID configurations and hot spare functionality ensure data redundancy and system resilience, minimizing the risk of data loss or system downtime.
    • Reliability: Hot-swappable hard drives, health monitoring, and cloud-based firmware upgrades enhance system reliability and availability, reducing maintenance and downtime.
    • Flexibility: Remote access and cloud upgrade capabilities provide flexibility in system management and maintenance, enabling convenient access and updates from anywhere.
    • Storage Capacity: The support for up to 16 HDDs provides ample storage capacity for storing large amounts of video footage, ensuring long-term retention and compliance with retention policies.
    • Professional Support: Installation, repair, and replacement services provided by CCTV specialists ensure proper setup, maintenance, and functionality of the NVR system, maximizing its performance and longevity.

Overall, the UNV POE NETWORK NVR NVR516-E-R offers advanced features, reliable performance, and comprehensive surveillance capabilities, making it an ideal solution for professional surveillance applications.

Support Ultra 265/H.265/H.264 video formats

64/128-channel input

Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols

Support 2-ch HDMI, 2-ch VGA, HDMI1 at up to 8K(7680×4320) resolution, HDMI2 at up to 4K(3840×2160) resolution

VGA1 and HDMI1 simultaneous output, VGA2 and HDMI2 simultaneous output. VGA1/HDMI1 and VGA2/HDMI2 independent output

Up to 32 Megapixels resolution recording

Redundant power supply optional

Support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable

16 SATA HDDs, up to 16TB for each HDD

Support 12V power output

ANR technology to enhance the storage reliability when the network is disconnected

Support cloud upgrade

Support N+1 Hot spare

UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace

1. Collection from SGCCTV   Choicecycle Sim Lim Square CCTV SPECIALIST #02-81 11am~8pm. Whatsapp 98534404 for stock level before visit.  2. Payment by PayNow 201207820G

UNV CCTV Camera Packages :
CCTV Camera Package 4MP-4CAM Uniview UNVP4  || CCTV Camera Package 4MP-6CAM Uniview UNVP6  ||
CCTV Camera Package 4MP-8CAM Uniview UNVP8  || CCTV Camera Package 4MP-12CAM Uniview UNVP12  ||
CCTV Camera Package 4MP-16CAM Uniview UNVP16  ||

UNV Camera and PTZ :
UNV IP CAMERA DOME IPC322LB-ADF28K-H  || UNV IP CAMERA DOME IPC3535LB-ADZK-H Uniview  ||
UNV IP CAMERA PTZ IPC6424SR-X25-VF  ||

UNV IP CAMERA WIFI BULLET IPC2122LB-AF28 UNIVIEW  ||

UNV NVR :

UNV POE NETWORK NVR NVR301-04S3-P4  ||
UNV POE NETWORK NVR NVR516-E-R Uniview  ||

UNV UNIVIEW NVR SETUP VIDEO GUIDE UNIARCHCCTV NVR UNIARCH NVR-108E-P8 NVR-104E-P4 UNIVIEW  ||

UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace



UNV NVR includes Easy, Prime and Pro series, which can be adapted to different application scenarios.
UNV NVR has high quality genes to ensure the reliability of devices and the whole system, focusing on user experience to simplify every operation process.
With excellent usability, reliability and capability, Easy series offers a wonderful choice for distribution / retail market;
Equipped with many practical functions and powerful decoding ability, Prime series fits well with projects and empowers the SMB market;
With large enough capacity, function and expansibility, Pro series provide the highest level of performance for vertical market.

UNV POE NETWORK NVR NVR516-E-R Uniview 64CH-128CH NVR Hot Swap RAID 0-1-5-6-10-50-60 N+1 Hot Spare Cloud upgrade 16-HDD CCTV Camera Installation Repair Replace

Specification

IPC6424SR-X25-VF
Camera
Sensor 1/2.8″, 4.0 megapixel, progressive scan, CMOS
Min. Illumination Colour: 0.003 Lux (F1.5, AGC ON)
0 Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 ~ 1/100000s
WDR 120dB
S/N >56dB
Lens
Lens type 4.8 ~ 120mm, AF automatic focusing and motorized zoom lens
Digital Zoom 16
Optical Zoom 25
Iris Auto; F1.5 ~ F3.8
Field of View (H) 52.20°~2.74°
Field of View (V) 30.81°~1.54°
Field of View (D) 64.20°~3.23°
DORI
DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m)
4.8 119.3(391.2ft) 47.7(156.5ft) 23.9(78.2ft) 11.9(39.1ft)
120 2475.0(8120.1ft) 990.0(3248.0ft) 495.0(1624.0ft) 247.5(812.0ft)
Illuminator
IR Range Up to 100m (328 ft) IR range
Wavelength 850nm
IR On/Off Control Auto/Manual
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
Frame Rate Main Stream: 4MP(2688*1520),Max 30fps;
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps;
Video Bit Rate 128 Kbps~16 Mbps
U-code Support
ROI Support
Video Stream Triple streams
OSD Up to 8 OSDs
Privacy Mask 24 areas, up to 4 areas per scene
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital Noise Reduction 2D/3D DNR
Smart IR Support
Flip Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise
HLC Support
BLC Support
Defog Digital Defog
Intelligent
Smart Intrusion Prevention Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection
People Counting Support people flow counting and crowd density monitoring
Events
Basic Detection Motion detection, Audio detection, Tampering Alarm
Auto Tracking Support
General Function Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication,
User Authentication
Audio
Audio Compression G.711U,G.711A
Audio Bitrate 64 Kbps
Two-way Audio Support
Suppression Support
Sampling Rate 8 kHz
Storage
Edge Storage Micro SD, up to 256 GB
Network Storage ANR,NAS(NFS)
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API,SDK
User/Host Up to 32 users. 3 user levels: administrator, operator and common user
Security Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Client EZStation
EZLive
EZView
Web Browser Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Pan & Tilt
Pan Range 360° (endless)
Pan Speed 0.1°/s ~ 200°/s
Preset speed: 240°/s
Tilt Range –15° ~ 90° (auto reverse)
Tilt Speed 0.1°/s ~ 120°/s
Preset speed: 200°/s
Number of Presets 1024
Preset Patrol 16 patrols, up to 64 presets for each patrol
Route Patrol 16 patrols, up to 32 actions for each patrol
Recorded Patrol 16 patrols, up to 128 actions for each patrol
Patrol Stay Time 15s~1800s
Preset Image Freeze Support
Home Position Support
Interface
Audio I/O 1/1
Alarm I/O 2/1
Serial Port 1 RS485
Built-in Mic N/A
Built-in Speaker N/A
WIFI N/A
Network 1 * RJ45 10M/100M Base-TX Ethernet
Video Output 1 BNC
Certification
EMC CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety CE LVD (EN 62368-1:2014+A11:2017)
CB (IEC 62368-1:2014)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment CE-RoHS (2011/65/EU;(EU)2015/863)
Protection IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
IK10 (IEC 62262:2002)
General
Power DC12V(±25%,3A), PoE+(IEEE 802.3at)
Power consumption: MAX 21W
Power Interface Ø 5.5mm coaxial power plug
Dimensions (Ø x H) Ø166 x 295mm (Ø6.5” x 11.6”)
Weight 3.05kg(6.72lb)
Working Environment -40℃~70℃(-40°F ~ 158°F),Humidity: ≤95% RH (non-condensing)
Storage Environment -40℃~70℃(-40°F ~ 158°F),Humidity: ≤95% RH (non-condensing)
Surge Protection 6KV
Reset Button Support
